💳 QR Pay Series

QR Pay Locker

Self-Service Storage · Scan to Pay

Scan → Choose Locker → Pay · Google Pay / Apple Pay / Credit Card supported · Retrieve by phone number + code

Scan to Open
QR Pay Locker

Scan-to-Pay Makes Storage Easier

QR Pay Smart Locker

Users scan a code with their phone to choose a locker and complete payment—fully self-service, with no staff needed. Google Pay, Apple Pay, Credit Card, and Membership Card are supported, so users worldwide can pay in their preferred way.

  • Scan with a phone to open—no app download required
  • Supports Google Pay, Apple Pay, Credit Card, and Membership Card
  • Phone out of battery? Enter your phone number + code to retrieve items
  • Flexible pricing settings with automatic revenue settlement

Scan to Open

Scan a code with your phone to choose a locker; the door opens automatically after payment

Global Payment Methods

Supports Google Pay, Apple Pay, Credit Card, and Membership Card for global users

Phone Number Retrieval

If your phone is out of battery, enter your phone number + code to retrieve items

Auto Revenue Settlement

Flexible pricing settings with automatic revenue reporting

Simple and Fast

1. Scan

Scan with your phone to choose a locker

2. Pay

Choose Google Pay / Apple Pay / Credit Card / Membership Card

3. Open

Door opens automatically after payment

4. Retrieve

Open with a code or phone number + code

Product Anatomy

Click a hotspot to learn more

QR Pay Locker Structure Diagram
QR Code Scanner
Payment Module
Touch Screen

QR Code Scanner

Industrial-grade scanner supports Google Pay, Apple Pay, Credit Card, and Membership Card—ready for global markets.

  • 0.2s instant scan
  • Multi-payment platform support
  • Auto receipt printing

Technical Specifications

Unlock Method
QR Scan + Phone Number + Code
Payment Methods
Google Pay, Apple Pay, Credit Card, Membership Card
Screen Size
8–11-inch Android touchscreen
Number of Doors
8 / 12 / 16 / 24 Doors (Optional)
Touch Screen
8–11-inch Android capacitive touchscreen
LCD Screen
8–11-inch full-view IPS display, brightness 250-300 nits
Aspect Ratio
16:9
Resolution
1024 × 600
CPU
Android 9.0+; 8-core 64-bit 1.6GHz
RAM
2GB DDR
Storage
16GB eMMC
4G
Optional (Quectel EG25)
WiFi
Supported
Ethernet
Supported
USB 2.0
2 ports
Serial Port
RS485 + RS232 + TTL reserved
Audio
3W / 8Ω dual channel
TF Card Slot
Supported
Input Voltage
AC 220V / 50Hz
Material
Iron / Stainless Steel / ABS Plastic (Optional)
Protection Rating
IP65 front panel waterproof
Operating Temperature
-20°C to 60°C (wide-temp design)

Use Cases

Malls & Supermarkets

Short-term storage for shoppers

Scenic Areas & Stations

Short-term luggage storage for travelers

Gyms

Temporary storage for members

Hospitals

Storage for patients' families and visitors

Scan-to-Pay Makes Storage Simple

Contact us for a product demo and a tailored quotation
